Cold Cutting, Folding And Sewing Machine For Cement Bag

Machine Introduction 1.Cold Integrated Cutting, Folding And Sewing Machine For Cement Bag Machine Technical Parameter Diameter of the roll fabric ≤1200mm Finished product bag cutting width 350-550mm Finished product bag-cutting length 500-950mm Fold height 90-120mm Bag cutting accuracy ±1mm Production speed 30-35pc/min Total power 16KW Installation dimension 9100mm*6200mm*1600mm 2.Cold Integrated Cutting, Folding And Sewing Machine For Cement Bag Machine Feature This machine adopts automatic PLC control, touch screen operation, servo drive, and offers selected cold-cutting or hot-cutting models. Cold Cutting: The first set of cutters is made of imported materials, ensuring durability and practicality. Fold size is easily adjustable, and bag length specifications can be adjusted with a single button. Features include automatic feeding, automatic deviation correction, automatic alignment, automatic counting, batch feeding, thread breakage alarm, and automatic stop prompts for malfunctions and joints. This machine is suitable for putty powder bags, calcium powder bags, single-color bags, double-color bags, and laminated bags, etc. 3.Cold Cutting, Folding And Sewing Machine For Cement Bag Configuration List Configuration List NO. Name Brand Spec QTY Unit Remark 1 Permanent magnet low-speed synchronous motor 110TDY115-2(110W)220V 3 set 2 YE2-90S-6 0.75KW 380V 1 set 3 Three-phase asynchronous motor YE2-90S-4 1.1KW 380V/220V 2 set 4 GH-22-30 0.4KW 220V/380V 1 set band brake 5 Three-phase asynchronous motor GH-22-20 0.4KW 220V/380V 1 set band brake 6 KZB130ST14620DE22 3.1KW 1 set 7 Gear reduction variable frequency motor KZA80ST0425BE22 1.0KW 2 set 8 DNBB18-003 BK1AMS 3.0KW 380V 1 set 9 Gear reduction variable frequency motor JXWY-2 0.75KW 3 set 10 51K120GU-15KUF 1 set 11 Servo motor + servo unit XGB-4KW 1 set 12 SC125*250-CA-Y 2 set 13 Servo motor + servo unit TGC40*75 2 set 14 SCJ63*100-50 1 set 15 Cycloidal motor AL4000-04 2 set 16 MBL25*75 2 pcs 17 Micro motor MBL32*35CA 4 pcs 18 MBL32*75CA 3 pcs 19 Vortex air pump MA32*10SCA 1 pcs 20 · 4N210-08-B · socket with plug DC24V PT 20 pcs 21 PLC DVP-80EH 1 set 22 Human-Machine Interface DOP-BO7S411 1 set 23 Switching Power Supply IDEC OS5R-SG24 1 set 24 Power Amplifier Board PLC-ZHB-1C.PCB 1 pc 25 Frequency Inverter AC70E-T3-1R5G 8 set Why Choose Us?

Product Details
